DC/DC Converter

go to order options

The DC/DC converter provides you with two stabilized reference voltages for your applications, which can be used e.g. to supply sensors. We offer you the combinations of 17 V and 5 V, 10 V and 5 V or 5 V and 3.3 V.

Downloads
Technical details

Inputs and Outputs

Number of pins 4

Mechanical Properties

IP rating IP6K8
Housing material PA66GF30
Dimensions 30 × 30 × 40 mm

General Information

Temperature range -40 to +85°C
Operating voltage 7-32 V, 12-32 V oder 19-32 V
Current consumption 6 mA @12 V und 24 V

Markings

Order options
Order no.Name
1.044.300.00
Reference voltage output 5 V / 10 V
1.044.300.05
Reference voltage output 5 V / 3,3 V
1.044.300.17
Reference voltage output 5 V / 17 V
